Major Features

Small in volumelight in weight and convenient in carrying
Operation of the product is simple ,low power consumption
Operation menu for the function setting
SpO₂ value display
Pulse rate value display, bar graph display
Pulse waveform display
The display mode can be changed
Screen brightness can be changed
A pulse rate sound indication
With measured data overruns limits and low-voltage alarm function, the upper/down alarm range is adjustable
Battery capacity indication
Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage ,and with alarm function
With SpO₂ value and pulse rate value of storage, the storage data can be uploaded to computers
Real-time data can be transmitted to computers
Connected with an external oximeter probe
Wireless communication function (CMS60CW)

Main performance

Display Mode: 1.8" TFT color LCD display
Screen Resolution: 160*128
SpO₂ Measuring Range: 0%~100%, (the resolution is 1%).
Accuracy: 70%~100%: ±2% ,Below 70% unspecified.
PR Measuring Range: 30bpm~250bpm, (the resolution is 1bpm)
Accuracy: ±2bpm or ±2% (select larger)
Measurement Performance in Weak Filling Condition:
SpO₂ and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO₂ error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).
Resistance to Surrounding Light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
Power Consumption: less than 100mA
Power Supply: Voltage 3.7 rechargeable lithium battery × 1
Battery Working Hour: 26 hours
Battery working life: Charge and discharge no less than 500 times.
Safety Type: Interior Battery, BF Type

Accessories

Sell in standard:
A lithium battery
A user manual
A USB line
A disk (PC software)
An oximeter probe
A power adapter (GTM41076-0605;CMS0105)
Sell in addition:
Other oximeter probe(Refer to probe application instruction for details and notice renewal)
Physical Identity
Dimension: 87(L) × 45(W) × 22(H) mm
Weight: About 175g (with the lithium battery*1)

Qualification

CMS60C passed FDA and CE
